KEY

PART

PART NAME

DESCRIPTION

NO.

NO.

I

1749

Cap Screw

1/4 - 20 x 2 1/2

1748

Cap Screw

1/4 - 20 x 2

2

1654

Bolt

5/16 - 24 x 2 3/4 Hex. Head

3

744

Hex. Nut

5/16 - 24

4

1726

Motor Chain Guard - 70" and 75" Inner

1747

Motor Chain Guard

5

1699

Motor Chain Guard Spacer

1700

Victor Chain Guard Spacer

6

1725

Motor Chain Guard - 70" Outer

1727

Motor Chain Guard - 75" Outer

7

1370-1

Hex. Nut

1/4 - 20

2167

Handle Bar 30" Assembly with #704 and #705 Brazed

9

787

Spring

5/8 x 7/8 (60#)

10

1633-1

Motor Chain Guard Bracket

1633

Motor Chain Guard Bracket - 70" Reverse Only

11

1507

Motor Sprocket 20T. Offset-14R6 Motor

3/4 P. - 1" Bore

1759

Motor Sprocket 24T. Offset-14R6 Motor

3/4 x 1/2 x 15/32 1" Bore

1760

Motor Sprocket 26T. Offset-14R6 Motor

3/4 x 1/2 x 15/32 1" Bore

12

708

Cap Screw

3/8 - 24 x 1 Hex. Head

724

Hex. Nut

3/8 - 24

13

707

Cap Screw

3/8 - 24 x 3/4 Hex. Head

14

1070-X3

Tractor Roll Assembly (Rubber) Includes 1 - #842, 1 - #1381

15

1205

Motor Sprocket 17T. 8R6 and 8BR6 Motor

5/8 - 3/8 x .400 (.750 Bore)

2029

Motor Sprocket 20T. 14R6 Motor

3/4 - 1/2 x 15/32 - 1 " Bore

1228

Motor Sprocket 20T. 8R6 and 8BR6 Motor

5/8 - 3/8 x .400 (3/4" Bore)

2161

Motor Sprocket 24 T

3/4 - 12 x 15/32 - 1 11 Bore

16

2120

Screened Blower Intake Stock for 81351 Motor

17

1838

Starter Pulley - 8R6 and 6R6 Motor

18

1839-1

Starter Pulley Hex. Extension R.H. Thread

19

1046

1" Conduit Lock Nut (Exhaust Pipe Lock)

20

1499

I" Street E I bow 45 0

21

1350-1

Set Screw

1/4 - 28 x 1/4 Cup Point

22

1607

Speed Control Rod Adjusting Collar

23

1606

Speed Control Bell Crank - Governor

23A

1888

Shoulder Bushing for Bell Crank (B & S #23849)

24

1613

Speed Control Rod 30" Long for 14R6 Motor

25

1624

Speed Control Rod to Governor - 14R6 Motors

26

1614

Speed Control Rod to Bell Crank

Speed Control Rod to Bell Crank for 25" and 70" Mowers

27

744

Hex. Nut

5/16 - 24

28

923

Washer

11/32 x 3/4 x 1/16

29

1498

Nelson Type Muffler

30

1605

Speed Control Bell Crank - Handle Bar

31

1593

Motor Chain - 14R6 & 19R6 Motor

3/4 P. #60 -51 P. 38 1/4" Long

2133-1

Motor Chain 23R6 Item-23

3/4 P. #60 -54 P. 40 1/2" Long

32

1772

Motor Sprocket Key - 14R6, 19R6 and 23R6 Motor ..

1/4 - 1/4 x 3/4

33

761

Set Screw

5/16 - 24 x 7/16 Cup Point

34

761

Set Screw

5/16 - 24 x 7/1 6 Cup Point

35

1511

Blower Intake Stack - 14R6 and 19R6 Motors

2105

Blower Intake Stack for 23R6

36

1517

Starter Pulley - 14R6, 19R6 and 23R6 Motors

37

1594

Starter Pulley Hex. Extension - 14R6, 19R6 and 23R6 Motors

37A

1594-1

Starter Pulley Hex. Extension - 19AR6 Only

38

2210

3/8" Street Elbow

39

1510

Drain Plug

3/8" Pipe Plug
